Products: Twisted-In-Wire Brushes

Twisted-In-Wire brushes are known by many names, such as spiral, tube, flue, bottle, pipe, boiler or power brushes. They all represent the same brush construction. In essence, a piece of wire is doubled over and bristle material is inserted between the fold of the wire stem. The wire stem is then twisted into a brush. Ends of the brush can vary, depending on your needs. For example, a brush can have a cut tip, rounded tip or bristled tip. It can have a long end or handle, a short end, one with a ring, loop or cut.

Typically the bristle material is located at one end of the brush, and the handle extends from it. However, the bristle can be centered in the wire, with two long ends, one on each side.

There are standard lengths for the brush part and wire but Gordon Brush can make whatever you need. See the table listing below for some of the sizes available.

Brush Type	Brush Diameter	Brush Length	Overall Length	End Types	Base Wire Types
Micro Spiral	.028" (.7mm)- .125" (3.2mm)	.125" (3.2mm)- 1" (25mm), Longer On Request	.625" (16mm)-16" (406mm)	Cut, Rounded, Tufted, Loop, Ring	Stainless Steel
Regular Spiral	.126" (3.2mm)- 16" (406mm)	.50" (13mm)-24" (610mm)	.625" (16mm)-As Long As Needed	Cut, Rounded, Tufted, Nipple Loop, Ring	Stainless Steel, Galv. Steel, Aluminum
Double Spiral	1/2" (13mm)- 3" (76mm)	2-1/2" (64mm)- 4"(102mm)	5" (127mm)- 7" (178mm)	Cut, Threaded, Nipple	Stainless Steel, Galv. Steel
Paddle Brushes	1/4" (6mm)- 1-3/16" (30mm)	9/16" (14mm)- 5/8" (16mm)	2-1/8" (54mm)- 2-1/4" (57mm)	Cut	Stainless Steel, Galv.Steel
